CORE SWX has announced new Helix Battery Brackets for SmallHD Monitors. These are available in AB Gold mount, V-mount, or B-mount.
The Dual Battery Bracket for SmallHD Production Monitors gives users the ability to power production monitors using 14v or dual voltage Helix Max batteries.
![Screen Shot 2023 06 01 at 8 34 54](/wp-content/uploads/2023/06/Screen-Shot-2023-06-01-at-8.34.54-740x574.jpg)
The Battery Bracket will work with all of SmallHD’s 4K production monitors.
![Screen Shot 2023 06 01 at 8 09 30](/wp-content/uploads/2023/06/Screen-Shot-2023-06-01-at-8.09.30-740x605.jpg)
The smart battery bracket slides down the Arca Swiss SmartRail located on the back of your monitor. This allows you to power your monitor and create a cable-less power connection.
Key features
- Output: DC 22-34v
- Size: 4.2” x 12.4” x 0.8″
- Weight: 1.3lbs.
- Input Voltage: Support 14v V-mt packs and Helix Max V-mt packs
![Screen Shot 2023 06 01 at 8 09 22](/wp-content/uploads/2023/06/Screen-Shot-2023-06-01-at-8.09.22-740x619.png)
The dual battery bracket also enables hot-swapping between the two battery plates, allowing for an uninterrupted power supply. It also allows for hot-swapping between the battery plate and the monitor itself using the 3-pin XLR power port.
The inclusion of 2x P-taps, each providing up to 2A of power, allows you to also power accessories from the bracket.
![Screen Shot 2023 06 01 at 8 32 05](/wp-content/uploads/2023/06/Screen-Shot-2023-06-01-at-8.32.05-740x368.png)
SmallHD does offer its own Dual V-Mount Battery Bracket (14v/26v) and Dual V-Mount Battery Bracket (14v/26v) for SmallHD 4K Monitors, however, they don’t offer a B-mount version. It is nice to see a third-party plate now available.
Price & Availability
The CORE SWX Helix Battery Brackets for SmallHD Monitors are now available for $389 USD.
