Core SWX has announced its new NANO Micro 50 V-mount and AB Gold mount batteries.

The NANO Micro 50 are lightweight, compact batteries with a 49Wh capacity. They look like a good solution for use with smaller-sized digital cinema cameras that don’t draw a lot of power.

You could also use them to power monitors and other accessories if need be.

Key features

  • 49Wh Lithium-Ion V-Mount Battery
  • Supports up to 6A Continuous Draw
  • D-Tap & 5V USB Outputs
  • 4-Stage LED Status Gauge
  • Ultracompact, Travel-Friendly Size
Screenshot 2022 04 08 at 10 35 51 AM

The batteries feature a 14.8V output and they support up to 6A continuous draw. Despite being small and compact, they also come with a D-Tap output and one 5V USB Type-A port.

The NANO Micro can be charged on a Core SWX or most third-party V-mount chargers, as well as via the D-Tap port.

Price & Availability

The Core SWX NANO Micro 50 Lithium-Ion Battery retails for $199 USD. The Core SWX NANO Micro series is also available in capacities of 98Wh and 147Wh.

  • Capacity: 49Wh(14.8v, 3.3Ah)
  • Operational Voltage: DC 12v-16.8v
  • Size: 2.82″ x 3.93″x 1.49″
  • Weight: 0.8lbs.
  • Normal Runtime: (25w) 1.8hrs.
  • Load: 6A

The batteries are scheduled to start shipping in early May.
